10x38mm Fuse Clips For PCB
WESTKING's 10X38mm fuse clip stands out among competitors' offerings due to its distinctive design. Unlike many other products on the market that utilize materials such as brass or copper, WESTKING employs innovative materials that mitigate the risk of significant temperature rises in photovoltaic fuses, thereby reducing the likelihood of damage to the PCB.
Send Inquiry
Product Description
The 10X38mm fuse clip from WESTKING is unique compared to other manufacturers' offerings. Commonly, these products use materials like brass or copper, which can result in a considerable temperature increase in photovoltaic fuses, potentially causing damage to the PCB. However, WESTKING employs phosphor copper material with excellent elasticity and a tin plating, ensuring reliable contact with photovoltaic fuses, minimal loosening, and reduced additional heat generation. This focus on product detail demonstrates WESTKING's commitment to user safety.
Technical data
| •Rated voltage: | 1000Vdc or 1500Vdc |
| •Rated currents: | 32A |
| •Product Size: | 10x38mm or 10x85 mm gPV fuses link |
Standards
The performance depends on proper installation conditions and adherence to the insulation distances specified in the IEC 60664-1 standard.
KEY FEATURES/ADVANTAGES
Excellent elasticity phosphor copper with tin plating material
Easy to install
Space-saving design
Ensures tight contact
Non-spring reinforced construction
APPLICATIONS
• Clip contact designed for Ø10 cylindrical fuse links, available with screw fixation and PCB mounting options.
Certifications
is09001 iatf16949
Origin
China
ELECTRICAL CHARACTERISTICS
| type | use | Net weigh | packing |
| SFPV-C | PCB | 3g | 100pcs/box |
Dimensions (mm)
Compatible FUSE bases
